Enhanced Protection Systems Ltd.
Cybereye I
Cybereye I has been specifically designed for the Search & Rescue mission in more extreme weather conditions, this vehicle is truly a force multiplier. It has been developed and produced as the result of the company undertaking rigorous testing in high altitude, mountainous and urban regions with our portfolio of UAVs. Therefore, we are aware of the end usersrequirements for all operational environments. As a result of this testing we have produced a small ramp or air strip launched electrically powered vehicle, which has the following features...
GROUND CONTROL STATION
Waterproof case containing digital video receiver (L band / S Band / 256 AES encrypted / diversity) and aircraft comms modem
Ruggedised sunlight viewable touch screen tablet PC
Charging systems 12 - 36 v input
No tools required
Total weight 12 kg
Charging time 1 hour
AUTOPILOT
Onpoint targeting - aircraft will follow moving ground targets
Fully autonomous take off, landing and navigation
Click drag way points and loiter
Convoy protection capability
In-flight programming
Single person operation
PAYLOAD CONFIGURATION
Onboard MPEG 2 video recorder
Gimbal Stabilised CCD x 36 zoom 38,000 pixels (360° pan x 90° tilt) TI camera. 30 micron 320 x 240 (360°pan x 90°tilt)
2 kg payload
Convoy Protection
Running one copy of the Virtual Cockpit, users can easily operate multiple UAVs from the same ground station, through one datalink. Useful for Convoy Protection and Hunter Killer and Target Prosecution. The Commbox ground station now includes a GPS receiver which allows the home position to move with the convoy while UAVs follow.
Specification
Weight 10 kg - Wing Span 2.7 m - Length 940 cm - Height 36 cm - Ceiling 4,500 m - Maximum Speed 120 km/h - Loiter Speed 72 km/h - Operating Height 60 - 400 m - Range 40 km - Flight Duration 180 mins -
Features
Range 40 km - Endurance 3 hours - Real time analogue / digital encrypted video downlink - Autopilot System provides fully autonomous flight with in flight programming via click and drag on map overlay - Onpoint targeting allows convoy protection / man tracking - High visibility strobes - Rapid deployment - All equipment can be carried by two men in a small vehicle - Set up time is five minutes - Ramp / runway launch - Electric flight, no fuel required - Aircraft can be charged in 1 hour off a DC power source.
